BANDA Audioparts ELEC10K.1OHM Electra Bass Amp 10K - 1 Ohm Digital Amplifier 10000 Watts Rms 1-Channel Full Range
- GENERAL || Brand : BANDA Audioparts || Model Number : ELEC10K.1OHM || UPC : 7898713131691 || BANDA ELECTRA AMPLIFIER MODULE 10000 WATT BASS AMP @ 1 OHM || The ELECTRA line was developed especially for those looking for incomparable bass. ||
- It has a frequency response of 22Hz to 1000Hz. Due to this, the ELECTRA will only play Subwoofers, Bass and Woofers. The variable BASS BOOST feature 30 - 80hz by up to 12dB is a differentiator, further reinforcing the bass of your system. Designed on a bold 100% aluminum chassis, it works with a power of 10000 WRMS with 1 input channel for connection and an impedance of 1 Ohm. It has very low harmonic distortion and Clipping indicator, forced ventilation and short circuit protection. ||
- TECHNICAL SPECIFICATIONS || - Maximum Power 12.6v @ 1 Ohm: 10000 WRMS || - Maximum Power 12.6v @ 2 Ohms: 8000 WRMS || - Nominal Impedance Efficiency: 76% || - Input Voltage: 9 - 15V || - Input Impedance: 100K Ohms || - THD Maximum Power: <1.5% || - Input Sensitivity: 300mV to 8V || - Signal to Noise Ratio: 80dBs ||
- - Frequency Response: 22 to 1000Hz (-3dBs) || - HPF (Subsonic): 22 - 65Hz || - LPF (Crossover): 80 - 250Hz || - Variable Bass Boost: 30 - 80hz up to 12dB || - Recommended fuse: 600A || - Resting Current: ~2.5A || - Maximum Current (musical signal): 500A || - Maximum Current (sine signal): 1000A || - Power Cables (recommended min): 70mm / 0 AWG ||
- DIMENSIONS || - Weight (kg) : 9.2 Kg | 20.28 lbs. || - Height (mm) : 73 mm | 2.87 inches || - Width (mm) : 256 MM | 10.09 INCHES - Depth (mm) : 452 mm | 17.80 inches
