FBT AUDIO CS1000WH 12-inch Compact Line Array Sub Pole DPS USB Mixer Portable Active Sub/Sat Integrated System 600W + 400W RMS, 129 dB SPLSPECIFICATIONS || Configuration : 2 Way || Frequency response : 40Hz - 20kHz || Low frequency woofer : 12"" || High frequency driver : 6x 3"" || Maximum SPL cont/peak : 129 dB || Dispersion : 110 x 30 || Input impedance : 22kOhm || Crossover frequency : 180Hz || Input connector : XLR || AC Power requirements : 640VA || Built-in amplifier LF/HF : 1000w (600w LF + 400w HF) || Built-in amplifier peak LF/HF : 2000w (1200w LF + 800w HF) || Power cord : 5m IEC ||KEY FEATURES || 2-way speaker system || Subwoofer with a custom 12"" (320mm) long excursion speaker with a 2.5"" (64mm) voice coil || 6 x full-range, 3"" (70mm) neodymium high efficiency custom woofers with 0.75"" (20mm) voice coils || Frequency response of 40Hz to 20KHz || Onboard Class-D, switch-mode amplifier delivering 600Wrms + 400Wrms for LF and HF respectively || Built-in DSP with eight presets to suit every application || Variable volume between -4.5 / + 5 dB in 8 steps ||Control Panel w/ master volume, presets, satellite volume, HPF & LED status || Input & link via XLR and Neutrik SPEAKON for satellite connection || Dispersion 110 ° (H) x 30 ° (V) || Modular design allowing two systems to be configured as one single solution via optional accessories || Bass reflex stackable subwoofer in a birch plywood enclosure w/ die-cast aluminium handle & rubber inserts, plus M20 support & a custom pole-mount solution facilitating adjustable height & vertical aiming ||The satellite and pole are fully integrated into the subwoofer cabinet, where a push button system locks the satellite in place for transportation || The satellite is equipped with a coupling system for accessories which allow the extension of the length of the line array, positioning one atop the other. Alternatively, the same system allows the satellite to be permanently wall-mounted. || Ideal for both live applications and fixed installations ||Easily expandable to a total power of 8.000W peak (via a stereo system consisting of 4 x VERTUS CS1000, positioned two per side) || DIMENSION || Net Dimension (WxHxD) : Satellite - 105 x 530 x 120mm, Subwoofer - 565 x 373 x 450mm || Net Weight : 30kg || Transport Dimension (WxHxD) : 695 x 473 x 580mm || Transport Weight : 34kg
